The Kane's Wrath Troubleshooter
In de video below how to play Kanes wrath online, how to install the latest patch, 4K add-on
You need the following downloads
You need cnc-online in order to play online.
Map pack, Community patch
Most popular patches the community play on.
Please check the download section for all downloads
Official patch for RETAIL/DVD version
Download is NOT for Steam and EA app users.
Problems connecting, please check the connection troubleshooter
When I launch my game using the C&C:Online launcher, I get the following error:
CA public key patching routine failed
Solution: Set Steam, Origin or your DVD Game shortcut and the C&C:Online Launcher to launch as administrator, make sure to follow the Hooking procedure.
When I launch my game, I’m getting the following error:
Missing Required file “Ssleay32.dll”.
Solution: When you encounter this issue, make sure that you have followed the Hooking procedure, in some cases will you have to deactivate your Antivirus Software as it might block the hooking process.
I bought the games on Origin and the C&C:Online launcher keeps saying:
the installation cannot be found. Or: You can not login.
Make sure to run the game with admin rights. Also unhook your game again
Solution 1 (C&C3 & RA3): Go into Origin, click the game (in this case either C&C3 or RA3), click the settings button to the left of “play”. Click “Game Properties” and check the box “Disable Origin in game” afterwards and download the ultimate collection launcher Only if you are using the Origin Ultimate Collection
I’m having trouble using C&C:Online with Steam.
Solution: Make sure that you are following the Hooking procedure
1. If that does not work, set Steam and C&C:Online to launch as Administrator
2. After you hooked your game, you can Click the hook menu again and check if there is a small Tick next to the hooked game name
3. Check if your Antivirus contained any files from C&C:Online, as some AVs (Looking at you Norton Antivirus) like to bully C&C:Online and quarantine files from it.
4. If all fails create a support Topic and one of our specialists will help you.
source revora.net
Before you attempt any of these fixes, make sure that you have followed and done this: Unable to establish a connection
![Troubleshooter Cannot connect Kane's Wrath Troubleshooter cannot connect](https://kaneswrath.com/storage/2023/04/Unable-to-establish-a-connection-300x114.png)
Hooking procedure: Open the C&C:Online Launcher.
On the Top left side of the launcher will you see a small button labeled hook.
Click the hook button.
In the now visible menu, click the game you want to hook.
Close the C&C:Online Launcher.
![Kane's Wrath Troubleshooter 27 Kanes wrath online](https://kaneswrath.com/storage/2022/10/hook-cnc.gif)
Start up your game trough Origin, Steam, GOG, or your DVD Shortcut
before the game boots, the C&C:Online launcher should open.
There you click the game you want to play (IT HAS TO BE HOOKED FOR THIS)
the launcher will now start to start up your game, please note that it might take some time and even show “not responding” give it some time.
Note: especially Red Alert 3 takes a really long time to start on first startup, you can make it go faster after its first properly startup.
I get the following error when logging in:
the transaction timed out without receiving a response.
Solution: This usually happens when you’re logging in with your old nickname (the one used on GameSpy). You’ll have to make a claim here to get that back. We do this avoid impersonation. In the meantime, use a different nickname.
Could Not Connect to Kane’s Wrath Online: after you press multiplayer
![Kane's Wrath Troubleshooter 30 could not connect to kanes wrath online](https://kaneswrath.com/storage/2023/04/could-not-connect-to-kanes-wrath-online-300x117.png)
Solution: Check if you are connecting with the correct IP adres, if you use a vpn you have multiple IP options
![Kane's Wrath Troubleshooter 31 ip](https://kaneswrath.com/storage/2023/04/ip.gif)
Upon login, the game says:
The specified account or sub-account wasn’t found.
Solution: Make sure you have set up a Server Login and that you’re using the right information to log in (you can check under My Account on the website).
- For C&C3 and Kane’s Wrath, your account name is the Server Login name displayed under My Account on the website.
When I try to log in, I get the following error:
user supplied an incorrect password.
Solution 1: This can be caused by two things. Most commonly this happens when you don’t use the C&C:Online Password but the password you used to create your Revora account. Make sure you use the Server Password displayed under My Account.
Solution 2: This has been reported to happen when the nickname you are attempting to use is too long.
Solution 3: It is possible that you may be using a Foreign Version of Windows, possibly trigger the wrong characters or keyboard layout while attempting to login.
Please log into the website and change the Server Account Password to numbers only and give it another try. If still out of luck and believe something might be wrong with your account, please make a support topic here for further assistance. (Credits to ToxicShock for figuring this out)
Upon login, the game says:
The specified Online ID or account name is already in use.
Solution: Your nickname has probably been reserved. You need to claim your old nicknames. Activating them takes some time. Read the pinned topics. It can also be that a different user already is using a profile with the name you tried to use, in this case you will have to settle on a different nickname.
Upon login, the game says:
Your nickname is bugged as ‘1’ and will forbid online gaming.
Solution: This happens when your account name (your Revora Log In name) has forbidden characters. Please make a thread to request a Log In name change.
source revora.net
– I have trouble connecting to people online (this seems to happen in RA3 the most)
Solution 1: If you got the game(s) through The Ultimate Collection bundle, Download the launcher fix to prevent connection issues to people that don’t have The Ultimate Collection.
Solution 3: Make sure that your firewall is not Blocking the C&C:Online Launcher, Your game or Gentool. (Google can help you find out how you can check if your firewall is blocking something)
Solution 4: [NOT FOR RA3] Port forwarding: If, when starting a game, your connection always times out, try this:
Lists of Ports that the Games use in case you need it:
Kane’s Wrath
Tiberium Wars
Generals
Zero Hour
- Open UDP port 16000 in your router settings. Go here if you don’t know how. Use this to check if your port was succesfully opened.
- In the game go to Options > Network and enter 16000 as the static port.
Solution 5: Try opening your DMZ in your router settings. More information on how to do this can be found here.
For people using the TG799vn v2 Router have a look here -> http://forums.revora…ks-with-a-link/
Source revora.net
Kanes wrath 4gb auto-patch from Medstar
This tool reduce the out of memory crash
The game can only use 2GB of ram because
of the limitation of 32bit.
Many players have game crash issues specially on custom maps, large maps or playing mods.
By installing this you increase the ram memory to 4GB.
If you use the 4K mod you do not need this because the 4K mod already has the 4gb patch included.
Support
If you have any problems installing this patch contact us
in our Discord server.
Zypherbullet's World Building Guide
Creating a tournament map requires some planning first. Let's make a 2v2 map in a forest-like area that's medium sized. Start off in Worldbuilder by going to [File] -> [New]. Let's make it 500 units wide and 400 units high. This translates into 5000 feet in the X-direction and 4000 feet in the Y-direction. Let's set the border size to 30 and the initial height to 100.
![Kane's Wrath Troubleshooter 38 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414159477.png)
Let's draw a situation that places all 4 players, all the Tiberium fields and all the tech structures. We'll also include any heightened terrain and waterways.
Note that the map will be symmetrical, so we will have to focus on one corner, since we will just duplicate and mirror this one.
It is important that you test your map often to see if distances between players, tiberium fields, structures and tech structures are good.
Let's place a corner mountain, the big Tiberium field, the base ridge and the player position. Also make sure that the starting positions are flat, or else structure placement in-game will be a pain.
The mountain is made using the [Mound] tool
![Kane's Wrath Troubleshooter 41 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414159735.png)
The Tiberium low ground is made using the [Height Brush] tool
![Kane's Wrath Troubleshooter 42 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414159772.png)
You can smoothen out any rough edges using the Smooth Height tool
![Kane's Wrath Troubleshooter 43 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414159831.png)
Using the [Ramp] tool
![Kane's Wrath Troubleshooter 44 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414159932.png)
The ridge was made in the same way as the mountain.
Now find a place where you would like for the Construction Yard to appear. This is the starting position. Select the [Waypoint Tool]
![Kane's Wrath Troubleshooter 46 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414160010.png)
Under [Waypoint Location], it is important to make round numbers. My waypoint was placed at X: [689.336182] and Y:[ 3286.463867]. Let's change this to X:[700] and Y:[3300].
Alright, this corner is set up! Now for the easy part: duplicating! Also, don't forget to save your map!
Select the [Terrain Copy Tool]
![Kane's Wrath Troubleshooter 48 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414160089.png)
It may be a little difficult to find the middle of the map. You can open up a grid in [View] -> [Grid Settings] or [Ctrl+E]. Tick 'Show Grid' and 'Justify to 0,0'. Make sure your Z is above your map height, so let's set it to 101. Select a big spacing, like 500, and hit OK. Simply count the squares and determine the middle lines to the center.
If you're feeling tough, you can also click on the top left and drag to about the middle. Then, in the bar below the Worldbuilder, you can see the current coordinates of your mouse.
![Kane's Wrath Troubleshooter 51 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414161553.jpg)
Now for the copying part. Go to [Copy mode] and select [Flip] -> [Vertically]. Leave [Rotate] at 0 degrees and enable [Copy] -> [Terrain height].
A black grid preview will pop up when you move your mouse over your screen. If you go out of top-down [CTRL+F] view, you will see a preview of the mesh (mountains etc.) as well!
Back in top-down view [CTRL+F], place the black preview under your selected area. Make sure that the bottom left corner of the preview aligns with the bottom left corner of the map.
Simply click and you will have your new mirrored corner!
From here, you can do two things:
- Keep the selection and mirror it twice more, but now only [horizontally] and [horizontally and vertically].
- Select the entire left half of the map and mirror it horizontally
Alright, meshes: done! Don't forget to save!
Now let's add the remaining players. Fire up your grey matter or grab a calculator and let's do some math! Yay!
Keep in mind that the map is 5000 wide and 4000 high. The map's coordinates start on the bottom left where the border begins. Remember that [Player_1_Start] was placed at X:[700] and Y:[3300]? This was in the top left corner. Now let's add [Player_2_Start] in the bottom left corner. Their x-coordinate should be the same as Player_1, so that they are equally far away from the map border. Since the map is 4000 high and Player_1 was placed 700 feet below the top border (4000-3300=700), we can place [Player_2_Start] at X:[700] and Y:[700].
Using the same calculations, only now for the X-coordinates, we can determine that [Player_3_Start] on the top right corner must have X:[4300] and Y:[3300]. The waypoint has the same height as Player_1 (3300) and must be 700 feet away from the border (5000-700).
We can now stuff the calculator aside, as [Player_4_Start] has the same y-coordinate as [Player_2_Start] and the same x-coordinate as [Player_3_Start]: X:[4300] and Y:[700].
This is a good time to add skirmish players. Go to [Edit] -> [Edit Player List]. Press [Add Skirmish Players] and hit OK.
Player positions? Done!
Now go save your map, take a break, breathe some fresh air and post something funny on the Main Discussion forum.
Alright, our map is finished! What? No? Oh haha, of course! We forgot to add Tiberium fields!
There are four kinds of Tiberium fields. In Worldbuilder, select Place Object [P]
![Kane's Wrath Troubleshooter 55 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414502551.png)
Tiberium fields are circular and grow from the center out. According to the map drawing, we have more of an elliptical shape to the left and right side of the map. We can make this by placing two fields near each other and having them intersect a little bit. Field 1 was placed at X:[450] and Y:[2250]. Let's place the second one on X:[450] and Y:[1750]. On the other side, let's place the top one on X:[4550] and Y:[2250] and the bottom one on X:[4550] and Y:[1750]. Now do the same for the remaining green fields: place it, round the number and then mirror it onto the other fields.
Once we're done placing the green fields, let's add the blue ones: TiberiumFieldBlue. Nothing new here, you know what to do.
Alright, now that we have placed the fields, let's jump into the settings for the green fields. Select a field and under [Object Properties], go to the [Tiberium] tab. [Radius] determines how big your field will grow. Under [View] go to [Influences] and then select [Show Tiberium Field Radius] to see how big your field can be. [Max Field Value] determines when to stop growing and [Starting Field Value] does exactly as it says: it determines how much a field has grown at the start of the game. Let's set our max value for the side fields to 50.000 and start value to 35.000. The radius is 400. Let's keep the [Field Lifetime Max] at 0 and set the [Resolution] to 40. Keep the [Cluster Factors] at 0 and set the [Growth Rate(sec)] to 10.
Make the other fields similar. To find out if a map is balanced and the field settings are they way you want them to be, you will need to play the map and see if it feels good.
If there's too much Tiberium on the map, it may result in a spammy map type where players create lots of units. If there's too little Tiberium, then we can expect boring games, because players can't build much.
Alright, now that the green fields are set up, let's set up the blue ones. These are a bit different, because we want them to start off as dry fields. Let's set the [Radius] to 200, [Max Field Value] to 25.000 and [Starting Field Value] to 1. Set the [Resolution] to 40 and set the [Growth Rate] to 30 seconds. This makes it a slow growing field that will be of more importance later in the game.
Guidelines for 1.02+ maps are:
- 1st Tiberium field: green Tib, radius: between 250 and 300, max and starting field value: between 30000 and 35000, field lifetime max: 0, resolution: 40 (if the radius is small, there won't be enough room for the Tiberium crystals to growth; so you need to reduce the resolution value in order to the crystals growth less spaced), cluster scale and power: 1, growth rate: 10 secs.
- 2nd Tiberium field: same as 1st, but with growth rate: between 8 and 5 secs (8 if there is no third Tiberium field), and starting field value may be lower to the max value.
- 3rd Tiberium field: same as 1st, but with growth rate: between 7 and 4 (4 only if it is a very important contested field, like in Tournament Badlands), and starting and max field value: between 20000 and 30000 (50000 if it's a contested field)
- Blue Tiberium fields: max field value: 40000, starting field value: 1, growth rate: between 25 and 40 secs (better slower than faster)
Now there's one last thing to do: Make the very center of the Tiberium field pop out! Open up [Single Tile (T)] and under [Terrain Painting Mode] tick [Visibility]. Make sure it is set to [Not visible]. Now in top-down view paint over the inside part of the TiberiumField:
Tiberium fields: done! Let's save our map! Also, don't worry about the textures you see. This will be covered below.
Remember that I had drawn a waterway in the middle? Let's add that now. But Zypherbullet! We did the meshes at the beginning and mirrored it all. We can't go and add a waterway this late, can we?
Sure we can, since it's in the middle and the [Height Brush] tool works circular. To find the middle of the map, add a waypoint and set its coordinates to X:[2500] and Y:[2000]. Now select the [Height Brush] tool, set the [Radius] to about 100 and the [Brush Height] to about 50. Zoom in on the waypoint as much as possible and place our new height in the middle of the waypoint:
Now let's set the [Brush Height] to 100 and [Radius] to 50. Do the same thing we did before to create an island:
We all know an island is not an island if there's no water around it, so let's add some water. We can use the [Lake/Ocean Tool] or the [River Tool]. For this one, let's use the [Lake/Ocean Tool]
![Kane's Wrath Troubleshooter 60 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414507262.png)
[Max Alpha Depth (ft)] determines how deep you can see, in other words, how low the transparancy goes. Increasing this softens the edges of the waterway. [Deep Water Alpha] determines the overall see through. A deep water alpha of 255 doesn't allow you to see through. Reflection does... well what you would expect it to do. It reflects things. To make the reflection interesting, you can add a skybox. Select [Place Object (P)] and navigate to ByNativeType -> Civilian -> NONE and select BlueZoneSkyA or BlueZoneSkyB or go to Neutral -> MISC_NATURAL and select BlueZoneSkyStormA. Place the skybox somewhere in the middle of your map. (Egypt Reflection Water Skybox does not work in Kane's Wrath.)
Now go and increase the water height until it soothes you. Use the [Smooth Height] tool to make the edges nice and soft. Let's also place some bridges to allow for acces to the island. Go to Place Objects -> Civilian -> STRUCTURE -> Bridge1 (or any of the other bridges). The recommended way to place bridges is to place waypoints for the start and end parts of the bridge and then placing the bridge parts over them. Again, use the coordinates settings to mirror them nicely.
DO NOT ATTEMPT TO MANUALLY ENTER COORDINATES IN THE BRIDGE OBJECT PROPERTIES - THIS WILL CRASH YOUR WORLDBUILDER!
If your waterway is somewhat transparent, I suggest painting the area below it with a texture to make it look more natural.
Tropical island in the middle of our forest with bridges? Done!
I know you're eager to try out your map and at this point you can! But if we cover the next step first, then the real testing can begin. Save the map first, though.
Alright, our map is almost ready for testing, so let's go and add our tech structures. These structures are found under [Place Object] -> ByNativeType -> Neutral -> STRUCTURE.
First, place the ElectroMagneticPulseControlCenter at the same spot our middle waypoint was: X:[2500], Y:[2000]. Now go and place the Tiberium Spikes and mirror the placements. Nothing new here either!
Now that this is done, you can add other tech structures as you see fit. Perhaps add some bunkers near the ramps of the side Tiberium fields to add some protection or add Defensive Towers near the EMP Control Center. We can also place a garrisonable structure near our Spikes to either defend or harass them.
Tech structures. Yeah, done! SAVE! Now let's jump into the game and start testing it out!
Now that we have start positions, ground meshes, waterways, tech structures and tiberium fields, it's time to test it out. You can do so against other players or against a skirmish AI. You will mostly be focussing on distances and balance now.
Play the map a few times as different factions to see if one of them gets an advantage or disadvantage. Are the tech structures too close or too far away? Remember that different factions have different scout speeds so they may cut off each other's engineers at the start. Also how about the tiberium field expansion? Can you basecrawl there or do you have to move your MCV for it?
It is important that you place the tiberium field expansions at the right distance from the opponent's field.
During your testing, you should also look out for potential places for garrisonable structures. If you can run worldbuilder and the game simulateneously, then you can just hop back and forth to edit things.
When you save the changes in worldbuilder and then restart your map, you will see that changes have been added directly. Play again and see if everything feels better now. Edit and repeat until you are fully satisfied.
Is your map playable, fair and fun?
Great! Now let's save and... o that's right, you've probably done that a million times by now. Save anyway!
Alright, we now have molded our map, added player start positions, added tech structures and garrisonables and finetuned our tiberium fields. I fear however that the map looks a tad simple, don't you agree? Let's go and add some textures!
Before we start, it is incredibly helpful to make a texture palette, so let's do that first. I'm going to keep it fairly simple for this map, but you can (and should) use many textures. You will often find that textures that belong to a certain region blend well.
Let's pick a few grasses with different coloring, two mountain textures and a Tiberium texture for our Spikes.
The image shows a palette by region, somewhere on the map, but I suggest making a palette outside your map boundary. This way you can easily access it and using the [Eyedropper] tool
![Kane's Wrath Troubleshooter 64 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414335341.png)
How you decide to paint the map is entirely up to you. I usually select one main texture that I like and then flood fill the entire map
![Kane's Wrath Troubleshooter 65 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414334983.png)
Now let's add some details to the map. This is again entirely up to your taste. Painting the map is a great way to add randomness to it, so let's do just that. I suggest painting a texture first and then blending the edges using [Auto Edge Out (Shift+E)] and [Auto Edge In (Alt+E)] tools
![Kane's Wrath Troubleshooter 66 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414336480.png)
When you blend 3 or 4 textures, you are bound to come across poor blends. These are tiles that look odd. You can use the [Blend Single Edge (E)]
![Kane's Wrath Troubleshooter 67 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414336805.png)
Tiberium fields are usually textured differently, due to the tainting effect of Tiberium. Under [Textures], go to [Misc], scroll down and you will find 5 Tiberium textures that you can use. Of course, you can use any texture as you see fit, like rock, dirt or even just grass. To keep things simple, I will use grass textures to make the Tiberium fields:
You can delay painting the Tiberium fields until we have placed the field objects to display their radius (see below).
Alright, ground textures: check! Also, save that map!
Alright, we've come to the point where you have to experiment what you will wish to add to your map. Under [Object Placement], go to ByNativeType -> Civilian -> STRUCTURE and click on the very first object. Hold it over the grey 'invisible' area (beyond the map borders) and judge if it fits in your map. Using the arrow keys, move down the list until you find something that you like. Place it outside your map and repeat. Keep doing this until you hit the bottom. Now under ByNativeType -> Civilian -> MISC_MAN_MADE do the same. Once you're done, select every object, copy (or rather cut) them and paste them somewhere else (still outside your map). The reason for this is that the game doesn't recognize every structure in Worldbuilder. Only the objects that were copied properly are recognized by the game.
Now go and place the structures and objects that you like. The game can handle many objects, but may impact performance if you overdo it. For 2 player maps, you should not place more than 4500 objects. This includes trees, structures, fences etc. Also limit your road segments to about 1000.
4 player maps can handle about 3000 objects and 800 roads, while 6 player maps should not have more than 1600 objects and 500 roads. 8 Player maps should be limited to 800 objects and 300 roads. As for 10 player maps, they don't exist.
The amount of objects are stored in the bar below Worldbuilder:
This is the time to add some MISC_MAN_MADE objects around your Tech Structures and perhaps add some fancy road linings around them (more about roads below).
Make sure to mirror structures as much as possible! An easy way to do this is to create a set of objects like this:
Then under [Edit] go to [Group Edit Method] and select [As Group]. Select all of your objects that you want to duplicate and copy them. Paste them near your desired location and under [Object Properties] click the box next to [Angle] and type 90 (to turn it 90 degrees counterclockwise). Likewise, 180 degrees turns it around completely (note that this isn't a mirror!) and 270 degrees rotates it 90 degrees clockwise. To dust off your math skills: a full circle is 360 degrees (or 2π radians if you're that kind of nerd).
Object placement? Mostly done! Save the map now.
Now would be a good time to include some roads. Let's keep it simple by just adding two types of road for now: Use the [Road] tool ( R )
![Kane's Wrath Troubleshooter 72 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414515220.png)
Let's make a main road and add some side roads to that:
As you can see, I adapted the terrain to the roads, since roads often affect the ground below them. I also placed a pavement texture below the EMP Control Center and some DefensiveTowers. (Don't mind the waterway. It may look different from yours, but that's okay.) The roads need not be mirrored, since they don't affect gameplay, but having them roughly the same on each side is not a bad thing. Again, play around with different roads and see which ones you like. You won't have something like an Eyedropper to reselect a road, so what you will want to do is deselect everything, select a road icon on the map, then deselect that and hit ( R ) to bring up the Road tool with the desired road type selected.
We are now well on our road to finishing the map! But first, let's save the map again.
Now that nearly everything is in place, let's add some trees and shrubbery. Again, make a selection of trees and shrubbery you want to use. Select your [Grove] tool
![Kane's Wrath Troubleshooter 74 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414517216.png)
![Kane's Wrath Troubleshooter 75 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414517759.png)
Now start drawing boxes and look how your trees pop up. Neat! Fiddle around with the settings to see what works for you. You can always re-arrange trees by moving them with the [Select and Move] tool.
Now in the [Grove Options] replace the trees with bushes and repeat until you are satisfied. Make sure that the total percentage is 100%. This is a great way to balance your trees and shrubbery. Again, save the map.
We're almost done placing everything. The map could still use some natural objects, like rocks around the mountains. You should now be able to do this on your own, so go nuts!
This is also a great time to add [Scorchmarks]
![Kane's Wrath Troubleshooter 76 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414520820.png)
Note that scorchmarks may have edges of other scormarks in their corners when rotated. This is a glitch and of course should be avoided. Or taken advangtage of if you're very creative.
![Kane's Wrath Troubleshooter 77 IPB Image](http://www.gamereplays.org/community/uploads/post-148533-1416314706.jpg)
Save the map!
To make our map a tad more lively, let's add sound flags. Select [Place Object] and navigate to ByNativeType -> Neutral -> AUDIO. The sound flag name gives a good indication of what it sounds like, but you can always place the flag and listen for yourself. Make sure you have enabled your sound on your computer and under [View] scroll down using the arrow, then select [Listen To Map] -> [Play Enabled Ambient Sounds]. You can place bird sounds and howling sounds near mountains, water sounds near the waterway, FieldCalm sounds around your entire map and woodcreaks in your foresty areas. Again, do as you see (or rather, hear) fit.
Object placements? Sooooo done! Now save!
Alright, we're nearing completion of the map. Everything is in place and the map should be fully playable by now. Still, we want to make it a bit more to our taste, so let's adjust the lighting. Go to [Edit] -> [Global Light Options...] and fiddle around with the option until it is to your liking. [Ambient] determines the overall color of the map, [Sun] is the main light and [Accent 1] and [Accent 2] are similar to the sun, but more dim. The sun and both accents can have their own rotation and height setting. You can always come back and change the light settings again.
It is important that you create a light that's soothing for your eyes and looks natural.
Now let's add some Post Effects that make your map like a professional map. Under [Edit] go to [Edit Post Effects]. There are 3 usable effects: [BloomPostEffect], [LookupTablePostEffect] and [LightRaysPostEffect].
- [BloomPostEffect] gives your map a flare-y look. Tinker around to see what works for you. Don't overdo it!
- [LookupTablePostEffect] gives your map contrast. [Volume Textures] can be found in your install directory under Command & Conquer 3 Kane's Wrath\data\art. (Remember the one we placed at the start?) Usable files are the ones that end with _vol. For this map, let's give it a warm bluebluezone_vol and set the blend factor to a low 200. Although your map may look more beautiful with high LookUpTable settings, it may be too taxing on your eyes if you have to watch it for a long period of time.
- [LightRaysPostEffect] adds lightrays to your map. Lightrays may really add a touch of beauty to your map, but again, this may be too taxing on the eyes. So for this tournament map, let's not add it.
![Kane's Wrath Troubleshooter 78 IPB Image](http://www.gamereplays.org/community/uploads/post-148533-1416405964.jpg)
You can play around as much as you want to see what works best. You can also go back to your lighting settings and adjust these to fit your new look!
Remember to make it as little taxing as possible!
If you can, view the map in every LOD. Go to [View], scroll down and hit [Set LOD]. Choose your LOD and then again under [View], select [Reload Textures]. If you find a level of display that looks wrong, try to adjust the settings in your post effects and repeat until it works out well.
We're almost there! Let's add a macro texture too. Go to [Edit] -> [Select Macro Texture]. Click on the options and see which one suits you. If you can't find a suitable one, enable (or disable) [Stretch]. I like the stretched tscloudmed.tga.
Now last, but not least, add a cloud texture. [Edit] -> [Select Cloud Texture]. Again, click on different textures and see which one you like. I like cm1_cloud.tga.
Don't use cm_redzonea_cloud.tga, for the above reasons.
If you're not sure if your settings are okay and don't wish to stare at your map for 6 hours for the sake of testing (nobody would blame you), then it may be wise to just steal the settings from official tournament maps. Predatore has created many tournament maps, so it is likely that you stumble across a setting that looks like yours. The easiest way to steal the settings is to open up two instances of worldbuilder, opening the Global Light Options on both maps (yours and the one you're stealing from) and then adjusting your settings to match theirs. You can do the same for Post Effects.
When you do copy someone's settings, it would be fair to credit them for it. You can also slightly adjust your settings and pretend you did it all by yourself. Whatever floats your boat.
Wew, well we are almost there! Save your map and let's get to finalizing the map.
By now, you will probably have given your nearly completed map a few tries. You may have noticed a very awkward minimap... Oh dear... But fear not! We will make our own minimap, but better. Go to [File] -> [Save As] and save it with a name similar to your original, but with something like minimap behind it, to indicate that this is the file we'll use to create a minimap. First go to your [Post Effects] again and delete all of them. Remember how we painted some terrain to be invisible? Let's make them visible again (same way, but now select [Visible] instead of [Not visible]. Who would've guessed... Under [View], copy these settings:
![Kane's Wrath Troubleshooter 79 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414527439.png)
Also make sure to [Show Water].
Then go to top down view of your map and reset the camera view (middle mouse button by default). Zoom all the way out until all borders are visible:
Now make a screenshot using Print Screen, or Prt Scn or whatever your variation on it is. If you have Photoshop, great! Open it up and paste the image there. Use the Crop tool to cut the edges right past the map boundaries. You will have to flip the image as well, because for some reason, the game reads it up side down. Now go to [Image] -> [Image Size], check [Contrstrain Proportions] and replace the biggest number (either Width or Height) by 256, then hit [OK]. Go to [File] -> [Save As] and then save it as mapname_art and as format choose Targa (*.tga). Place the new file in the same folder where your original map is.
If you don't have a copy of Photoshop, you can try free software like GIMP or just send the screenshot to me and have me do it.
Minimap: done!
Now open up the original map (the one we've been working on before we created the minimap-specific copy). Go to [Edit] -> [Edit Map Settings]. This will most likely be the hardest part: coming up with a catchy map name! This will be the name that shows up in game. When you're done, let's move on.
Leave the [Compression] at [RefPack] and the [Time] just the way it is. Set the [Weather] to something that fits your map. Let's set ours to SUNNY. We'll also set [Music Zone] to [MusicPalette_BlueZone]. Untick [Is Scenario Multiplayer] and jump over to [Fog Settings]. Enable it, choose a fog color of your liking and set the [Start] to anywhere between 400 and 1000 and the [End] between 2500 and 5000. Just try and see what works for you in game.
Under [Camera Behavior] set the [Min Height] between 170 and 200 and the [Max Height] between 420 and 435. Keep the rest as is.
In the great white box below you can add comments, like a version number, a creator name or credits to someone who helped you out (hint hint). Now save the map again!
We are almost done now! You know how everything works, so scroll around your map and maybe add textures and meshes (rough terrain etc.). You can even use Google Images to get some inspiration. Also make sure to take a look at your waterway to try different settings and textures. The latter are found in your install directory under ../data/art.
Alright! We did it! We finished our map and we are still breathing! Now go into the game and play it on every detail to test it. Call up your friends and try the map out, ask the community what they think (unless you're in the worldbuilding challenge!) or play against AI. Try to find as many bugs and unbalances as you can find (however hard you try, there are always bound to be some) and fix them. Then update your map, change the name to something with v2.0, so you know which is the newest version and repeat. When you feel positive that your map is the best it can be, send it off to the players of the world and go fish for compliments. You've earned them. Although... If you're feeling tough, you can add one last thing: a few scripts to enhance your map just that little bit!
The scripts system is something apart and can drastically change your map if you know how to use them. For our map, we'll just add some very basic scripts: birds. YES! BIRDS! Goodness gracious balls of feathers.
Select your [Waypoints] tool and create a path by placing and then dragging it to the next location. Repeat this until you made a full circuit. It can be spread over the entire map, because birds are free to do as they please. [Under Waypoint Path Labels:] Type your desired name for your path, like Bird Path 1. Go to [Place Object] and navigate to ByNativeType -> Civilian -> UNIT and select CUBird01. Place one near the path and call it something like Bird 1 Path 1. Now go to [Edit Scripts (CTRL+ALT+R)]
![Kane's Wrath Troubleshooter 81 IPB Image](http://www.gamereplays.org/community/uploads/post-224937-1414530239.png)
Hit [OK] and then again hit [OK].
Using the same previous steps, you can add more birds (give them different numbers) and more paths. You can have multiple birds follow the same path too! These move actions can all be activated in the same script. Their path is a looping one, so they are deemed to fly in circles for the rest of their lives. Hah!
Save your game and watch them birdies go!
Congratulations, fellow builder. You are now trained in the basic ways of the Worldbuilder, but there is yet much to learn...
A big shoutout to:
Predatore for helping me write this tutorial. He is the master of all tournaments after all!
phantom9399 for organizing the challenge and putting a lot of effort into it.
ToxicShock and Plokite_Wolf for proofreading and making the read more enjoyable.
cnc315d34d for teaching me many things about worldbuilder
And all the others who helped me out, but who I can't seem to remember at this point. Sorry guys, but you rock anyway!
Direct3D error (Out of memory).
This error is caused by a corrupt or outdated installer of the Worldbuilder.
Most older Worldbuilder installers don’t include the 4gb patch.
Please use the download below which include the TGA files, object fixes and 4gb-patch
The application has failed to start because its side-by-side configuration is incorrect.
Make sure you have Microsoft Visual C++ 2005 Service Pack 1 Redistributable installed.
If it still give an error try the solution below.
The error could be because of a fault in the windows registry key.
VIDEO How to fix the registry
Step by Step manual
1. Open file explorer
and Goto C:\Windows\WinSxS
2. Type in seachbox top right vc80.crt
3. search the version that start with x86_microsoft.vc80.crt_1fc8b3b9a1e18e3b_8.0.50727 and ends the highest number, in this example we use 9672.
4. Open registry editor and goto:
Computer\HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\SideBySide\Winners\x86_microsoft.vc80.crt_1fc8b3b9a1e18e3b_none_bcc8f3fc9457ed28\8.0
Copy/Paste the line like in the screenshot below.
5. Add a new binary if the highest number does not exist,
right click your mouse and pick Binary value.
Name it 8.0.50727.(your-highest-number)
(your-highest-number) is your highest version number you found in C:\Windows\WinSxS
In this example its 8.0.50727.9672
Once you created the new Binary right click the new Binary and press on modify.
Do not use backspace just type in 01 and press on ok.
Thats it !!!
You may need to restart your Computer.
